Thermoplastic Resin TPU Hot Melt Adhesive Powder For DTF Transfer

Thermoplastic Resin TPU Hot Melt Adhesive Powder For DTF Transfer

  • High Light

    Resin TPU Hot Melt Adhesive Powder

    ,

    Thermoplastic TPU Hot Melt Adhesive Powder

    ,

    TPU Thermoplastic Resin Powder

  • Appearance
    White Powder
  • Composition
    TPU
  • Density ASTM D-792
    1.16±0.02 G/cm3
  • Melt Point DSC
    105-115 ℃
  • Powder Size Range
    0-80um 80-200um
  • Resistance To Yellowing (level)
    2.0-3.0
  • Temperature
    105-125℃
  • Press
    1.5-2.5 Kg/cm2
  • Time
    8-15 S
  • Washing Resistance
    60℃
  • Product Type
    TPU Hot Melt Adhesive Powder
  • Place of Origin
    China
  • Brand Name
    Easun
  • Certification
    Rosh, Reach
  • Model Number
    ES220
  • Minimum Order Quantity
    20KG
  • Price
    Negotiable
  • Packaging Details
    20KG/bag
  • Delivery Time
    3-8 working day
  • Payment Terms
    T/T
  • Supply Ability
    4000000

Thermoplastic Resin TPU Hot Melt Adhesive Powder For DTF Transfer

Thermoplastic Resin TPU Hot Melt Adhesive Powder For DTF Transfer

Product model: ES220

Description: TPU hot melt adhesive powder

TPU Hot Melt Adhesive Powder Function:Heat transfer,Digital printing,Silk screen printing.



Physical Characteristics:



Property Criterion
Appearance White powder
Composition TPU
Density ASTM D-792 1.2±0.02g/cm³
Melt Point DSC 105-115 ℃
Melt Index ASTM D-1238 30±5g/10min
Powder size range 0-80 um
0-170 um
80-200 um
125-200 um
150-250 um
180-420 um



TPU Hot Melt Adhesive Powder Technical Parameters:



Bonding parameters (for reference only) Temperature 105-120℃
Press 3.0 kg/cm2
Time 14S
Washing Resistance 40℃ Excellent
60℃ good
90℃ /



Packaging and Storage Conditions:

Packaging 20KG in one PE bag+Brown paper bag
Storage Conditions Stored in dry unopened packaging at room temperature for 12 months. High temperature and pressure will cause agglomeration. The trays cannot be double-pressed.



1. Bonding temperature and pressure and time relate to the bonding strength of the film to the material. The bonding temperature must be close to the temperature set by the machine, the pressure must be uniform, and the mold and press rolls must be flat.
